Comparing the white and black brightness profiles. (Red circle on glass scale)
Conventional lens
The blurred area around the border between black and white is wide, and the rise of the brightness profile is gentle.
High resolution 4K lens
The clear area around the black and white boundary is wide, and the brightness profile rises sharply.
That’s why High-definition video can be achieved!
Magnification/Field of View
Minimum magnification 23x
(field of view range 14.5mmx11.0mm)
Maximum magnification 230x
(field of view range 1.5mmx1.1mm)
General Specification
Magnification
23x～230x * Magnification is a calculated value converted to a 17-inch monitor
Working Distance
100mm
Field-of-view
14.5mmx11.0mm （23x）
1.5mmx1.1mm （230x）
Image Sensor
1/1.7”CMOS
Number of pixels
12MP
Pixel Size
1.85μmx1.85μm
Typical resolution （*Frame Rate）
4000×3036（30fps） * The actual frame rate will vary depending on the performance of your computer and the setting environment.
Working enviroment
Support OS
Windows7、8、8.1、10、11
CPU
Intel core i5 above
Memory
8GB above
Accessory
Camera USB3.0 12MP
Exclusive LED ring light
High resolution 4K zoom lens
Stand * Can be changed to a small stand
Protective cover
Viewer Software
Main features
● USB3.0 connection
● Equipped with a 10x optical zoom lens for a total magnification of 23x~230x
● Zoom lens with latch function that locks each scale (eliminate operator error, suitable for measurement)
● Can change to a small stand
How to install the camera（Youtube video）
Introduction of standard equipment software
Features of standard simple measurement software
Saving images
Distance measurement between two points
Display scale
Display crossline/gridline
Fit-in function, digital zoom function
Supported OS: Windows 8 or later
＊ This standard accessory software is a functionally limited version. Please purchase the optional measurement software if you need to measure other than the distance between two points or if you need a focus combination function
●Measurement assist (edge automatic fit) function ●Pinpoint digital zoom function ● Easy focus with roll focus composition function! GS-4SQ (20µm/100µm/500µm/with 4 types of scales in 1mm increments) is included as standard equipment
[Measurement items] ●Distance between two points ●Distance between parallel lines ●Distance between horizontal parallel lines ●Distance between vertical parallel lines ●Vertical distance ● Distance between circle centers ● Point coordinates ● Three-point specified angle ● 4-point specified angle ● 3 point designation circle ● Approximate circle ● Rectangle ● Oval ● Approximate straight line ● 3-point arc, etc
【Useful function】 ・Edge automatic fit function ・Pinpoint digital zoom function ・Scale display ・Focus stacking function ・Report creation ・Image merging function (tiling function)
●Focus stacking function
●Tiling（Image merging function）
Comparison between Standard viewer software (MFShip* with limited functions) and High-performance image processing measurement software (MFShip)
● The main differences are summarized in the table. Please choose according to the function you need
Standard viewer software
MFShip software
Measure distance between two points
○
○
Multi-function measurement
×
○
Edge auto-fit function
×
○
Focus composition function
×
○
Halation removal function
×
○
HDR composition function
×
○
Image merging function
×
○
Excel output
○
○
Thumbnail display of image data
○
○
Screen display magnification change
×
○
Cross line display
○
○
Grid scale display
○
○
Compatible OS
Up to Windows 11
Up to Windows 11
A wide variety of optional software is available!
●We have a wide variety of optional software such as measurement, focus stacking, automatic visual inspection, image linking, and graphite spheroidization rate measurement. Of course, you can also use your current commercially available applications (* DirectShow compatible).
